CLAAS AXION 930TT-960TT Tractor

AXION 900 TERRA TRAC - the first half-track tractor with full suspension.

CLAAS AXION 930TT-960TT Tractor

The all-new CLAAS AXION 900 TERRA TRAC series tractors are the next generation in tractor technology. Providing more traction for increased pulling power, reduced soil compaction to safeguard future harvests, and the world’s only fully suspended TERRA TRAC crawler track assembly and 4-point cab suspension that delivers a new standard of driver comfort. As a new solution for modern, efficient agriculture, the AXION 900 TERRA TRAC was awarded a silver medal at Agritechnica 2017.

CLAAS AXION 900 TERRA TRAC

Reduced soil compaction

Low ground pressure safeguards future harvests. The footprint of the crawler track assembly depends on the width of the track. If the front tyre contact area is included, it can be up to 4 m². This is 1 m² or 35% larger than a standard tractor.

Maximum stability

The front axle and the crawler track unit with a large angle of oscillation easily cope with the very uneven ground on farm tracks and at field entrances. So the vehicle remains stable even when using heavy attached implements.

Enhanced pulling power

The long wheelbase and front axle provide effective directional stability. Both crawler track assemblies deliver their full traction potential at all times, even under varying soil conditions. The vehicle’s weight distribution and the implement’s drawbar load have no effect on the behaviour of the TERRA TRAC crawler track units. Their oscillating motion keeps the track parallel to the ground whatever the working conditions.

Specifications

	930TT	960TT
Engine	FPT	FPT
Number of cylinders/intake	6/TI	6/TI
Cubic capacity (cm3)	8710	8710
Max. output (ECE R 120) (kW/hp)	261/355	327/445
Max. torque (Nm)	1695	1860
Max. fuel tank capacity (L)	860	860
Hydraulic load-sensing circuit (L/min)	220	220

Swipe to see more

Resources

Brochure

Technical Specs

TERRA TRAC Technology

Walk Around

Tractor Launch Video

Farm Machinery Sales Review

Comfort Highlight Video

Close Up of the Terra Trac Image

Back view of Tractor Image

CEMIS 1200

CEMIS 1200 serves as a modern, intuitive terminal for automatic steering and precision farming applications. The SAT 900 GNSS receiver mounted on the roof guarantees high precision and steering performance. Together, these two components of the GPS PILOT – seamlessly integrated into CLAAS machines – are a powerful combination.
